A flexible product that can be used on walls and ceiling to greatly control the sound in a room. Coated in ecopaint, they provide an attractive way to improve the acoustics of a room.
For further information, stock availabilty and to place your order, please contact our team.
EchoPro Multi sound absorbing acoustic panels are a flexible product that can be used on walls and ceiling to greatly control the sound in a room.
They are pre-finished in a clean white colour on all six sides, and are 40mm thick providing a class A absorber. They can also be suspended from the ceiling to provide sound absorbing rafts, or from their sides as baffles - giving a visual impact in addition to the acoustic benefits. EchoPro Multi is also available in circular shapes.
Applications for these tiles are wide and varied, and include:
Schools
Offices
Music Studios
Lecture Theatres
Multi-Purpose Halls
Interview Rooms
Training Rooms
Cinemas
And of course they can be used in the domestic environment too - providing incredible results in removing echo from rooms.
Product Application
EchoPro Multi acoustic panels are high performance class A sound absorbing panels suitable for wall and ceiling applications. They are pre-finished in a standard white colour but can be painted any colour using a suitable water based matt emulsion spray paint.
Used to absorb sound in environments such as schools, offices, leisure centres, community halls, hospitals, music and TV studios, churches and restaurants.
The wall panels are used extensively to transform areas such as multi-purpose halls, open-plan offices, conference suites, music and TV studios and interview rooms into workable environments.
Fire Resistance
This is fire rated as Class 0 to BS476: Part 6.
Weight
The 40mm thick EchoPro Multi panels weigh approximately 4kg/m2.
Clean white gloves must be used when handling these panels to avoid marking them. The acoustic panels are installed using impaling clips and Gluesorba contact spray adhesive.
This method allows the panels to be fixed direct to concrete, brickwork, wood, plaster, or metal. A site installation guide is sent with each delivery. The wall to which the Quietsorba acoustic panels are to be fixed must have a continuous solid backing wall surface, which must be level and flat.
The impaling clips have 4mm diameter holes to take pan head screws. Using appropriate screws and plugs, etc. depending on your wall substrate, fix the correct number of impaling clips needed for the size of the panel. The larger the panel, the greater the number of impaling clips.
Installation to Ceilings
Clean white gloves must be used when handling these panels to avoid marking them. The installation time is fast as the Quietsorba ecopaint acoustic panels are simply suspended by steel wires from the soffit by means of special spiral hooks which are fitted in the rear of the acoustic panels. Also, this means that non-specialist fitters can be used to carry out the installation.
The depth in suspension is simply changed by adjusting the length of the steel suspension wire. This also allows the panels to be installed at slightly sloping angles if required, again adding to the visual design possibilities. The spiral hooks should be placed between 200mm to 300mm from the edge of the Quietsorba panels.
The suspension kit consists of a spiral hook and adjustable 2m cable.
Visit our Fitting Instructions section for more detailed instructions relating to your specific application.
Check out our Soundproofing Guides for more information, advice and tips on all aspects of soundproofing.
